Fitting instructions :-
Assemble the cabinet as per dimensions shown in Fig.1. Possible to create different configurations
Insert the U-Clamps into bottom rod of basket and screw it to mechanism with help of fasteners provided as shown in Fig. 2 & 2a.
Fix mechanism onto the cabinet with the help of screws provided (10 nos.) as shown in Fig. 3 For additional details refer Drilling Diagram.
Note:
When product is installed in Lifting Door type cabinet 1, the door opening angle to be 60° minimum.
When product is installed in Opening Door type cabinet 2, if the inner depth of Cabinet is 295mm; kindly pay attention to the size and specification of the hinge for door.
